| 型号 |
外部尺寸（mm） |
工作温度（℃） |
频率范围 |
PDF下载 |
| AMPMDGB-50.0000,50MHz有源晶振,ABRACON艾博康晶振,1.71V ~ 3.63V,50PPM |
2.5x2.0x0.89mm |
-40°C+85°C |
50MHz |
PDF下载 |
| AMPMGED-25.0000,25MHz有源晶振,ABRACON艾博康晶振,1.71V ~ 3.63V,50PPM |
1.6x1.2x0.89mm |
-20°C+70°C |
25MHz |
PDF下载 |
| AMPMGED-24.0000,24MHz有源晶振,ABRACON艾博康MEMS晶振,1.71V ~ 3.63V,50PPM |
1.6x1.2x0.89mm |
-20°C+70°C |
24MHz |
PDF下载 |
| AMJMAFB-100.0000T,100MHz有源晶振,ABRACON艾博康MEMS晶振,1.71V ~ 3.63V,25PPM |
2.0x1.6x0.89mm |
-40°C+85°C |
100MHz |
PDF下载 |
| ACHL-40.000MHZ-EK,10MHz有源晶振,ABRACON晶振,3.3V,30PPM |
13.2x13.2x5.5mm |
-20°C+70°C |
10MHz |
PDF下载 |
| ACOL-8.000MHZ-EK,8MHz有源晶振,ABRACON晶振,3.3V,30PPM |
20.2x12.6x5.08mm |
-20°C+70°C |
8MHz |
PDF下载 |
| 100MHz差分晶振,AK2ADDF1-100.000T,LVDS晶振,ABRACON晶振,2.375V ~ 3.63V,25PPM,2520晶振 |
2.5x2.0x1.1mm |
-40°C+85°C |
100MHz |
PDF下载 |
| AK3APAF1-156.2500T,156.25MHz差分晶振,LVPECL晶振,3.3V,3225晶振 |
3.2x2.5x1.1mm |
-40°C+85°C |
156.25MHz |
PDF下载 |
| ABLNO-100.000MHZ-T2,100MHz压控晶振,ABRACON晶振,VCXO晶振 |
14.3x8.7x5.5mm |
-40°C+85°C |
100MHz |
PDF下载 |
| ACH-10.000MHZ-EK,10MHz有源晶振,ABRACON晶振,5V,30PPM |
12.7x12.7x5.6mm |
-20°C+70°C |
10MHz |
PDF下载 |
| 100MHz有源晶振,ABLJO-100.000MHZ-T,ABRACON晶振 |
14.3x8.7x5.5mm |
-40°C+85°C |
100MHz |
PDF下载 |
| Abracon艾博康晶振,ABS25-32.768KHZ-T,32.768KHz晶振,8038晶振,12.5PF,20PPM |
8.0×3.8×2.5mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| 6MHz晶振,ABSM2-6.000MHZ-4-T,艾博康abracon晶振,18PF,50PPM |
12.5x4.5x3.7mm |
-10°C+60°C |
6MHz |
PDF下载 |
| 100MHz有源晶振,ASEMPC-100.000MHZ-LR-T,ABRACON晶振,2.25V ~ 3.6V,25PPM,3225晶振 |
3.2x2.5x0.9mm |
-40°C+85°C |
100MHz |
PDF下载 |
| ABDFTCXO-10.000MHZ-L-2-T5,ABRACON晶振,TCXO温补晶振,3.3V,±280ppb |
14.2x9.15x3.1mm |
-40°C+85°C |
10MHz |
PDF下载 |
| 200MHz差分晶振,ABFM1-200.000MHZ-V-T,LVDS晶振,ABRACON晶振,5070晶振,2.5V,50PPM |
7.0x5.0x2.0mm |
-0°C+70°C |
200MHz |
PDF下载 |
| ABS13-32.768KHZ-T,32.768KHz晶振,Abracon艾博康晶振,12.5PF,20PPM |
6.7x1.4x1.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| ABS07-32.768KHZ-T32.768KHz晶振,ABRACON艾博康晶振,3215晶振,12.5PF,20PPM |
3.2x1.5x0.9mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| 32.768KHz贴片晶振,ABRACON艾博康晶振,ABS09-32.768KHZ-T,12.5PF,20PPM,4115晶振 |
4.1x1.5x0.9mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| ABS06-127-32.768KHZ-T,32.768KHz晶振,ABRACON艾博康晶振,2012晶振,12.5PF,20PPM |
2.0×1.2×0.6mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
